AC Condenser Compressor Replaces Copeland YHC1-0350-PFV, YHL1-0350-PFV

(No reviews yet) Write a Review
UPC:
CMP63 605-U5
  • YHC1-0350-PFV YHL1-0350-PFV
$1,249.00

Description

This is a brand new 3.5 - 4 Ton's 208/230 Volts 1-Phase Direct Factory Replacement Copeland Compressor. The Model # is CR42K6E-PFV-875.

TECHNICAL SPECIFICATIONS.



Tonnage:3-1/2 to 4 Ton Depending on Equipment Models
Voltage:208/230.
Running Current Amps:20.5
Line Connection Discharge Inside Diameter 1/2 Inch.
Line Connection Suction Inside Diameter 7/8 Inch.
Base Mount Hole Center Size 7-1/2 x 7-1/2 Inches.
Length 9-7/16 Inches.
Height 15-3/16 Inches.
Width 9 Inches.
Refrigerant: R22.
Series:CR
Crank Case Heater:Yes.

Run Capacitor is 50uf 440 volt.Most condensing unit capacitors are dual capacitors, meaning they operate thecompressor and the fan. To purchase the correct capacitor you will need toknow the uf rating on the fan.

Start Capacitor. 189-227 330Volt


To properly install a Compressor you need to have and use the proper equipment and use proper installation technique. If you are not familiar with these techniques or you do not have the proper equipment then you SHOULD have a qualified HVAC tech to install your new compressor. If the compressor is damaged due to improper installation procedures, the liability falls to the installer. All Sales are Final and there are no warranties!



Replaces:
Difficulty Level
Repair Difficulty Level
