AC Condenser Compressor Replaces Bryant Carrier Payne P021-4722

This is a 3.5 - 4 Ton's 208/230 Volts 1-Phase Direct Factory Replacement Copeland Compressor with Model # CR47KQ-PFV-970. It is designed to replace old Copeland Model #s CR47KQ-PFV-980WB & CR47KQ-PFV-980WP. In some instances, small piping changes may be needed. Thanks for looking and good luck!

TECHNICAL SPECIFICATIONS.

Capacity (Btu/hr): 40400
Power (Watts):4080
Current Amps: 24.6
EER (Btu/Wh): 9.9
Refrigerant: 22
Overall Length:10.375"
Overall Width: 9.094
Overall Height: 14.812
Suction Size (in): 7/8”
Discharge size (in): ½”

* Compressor Electrical Data:

Voltage:208/230
Phase: 1
RLA: 24.6
LRA: 132.0

Run Capacitor is 45uf 440 volt.Most condensing unit capacitors are dual capacitors, meaning they operate thecompressor and the fan. To purchase the correct capacitor you will need toknow the uf rating on the fan.

Start Capacitor. 189-227 330Volt

To properly install a Compressor you need to have and use the proper equipment and use proper installation technique. If you are not familiar with these techniques or you do not have the proper equipment then you SHOULD have a qualified HVAC tech to install your new compressor. If the compressor is damaged due to improper installation procedures, the liability falls to the installer. All Sales are Final and there are no warranties!
