AC Condenser Compressor Replaces Copeland CR30K6-PFV-870, CR30K6-PFV-877

This is a 2.5Ton 208/220 Volts 1-PhaseDirect Factory Replacement Compressor (Copeland) The Copeland Model # is CR30K6E-PFV-875. It is rated at 34,500 BTU.In some instances, small piping changes may be needed. Thanks for looking and good luck!

Tech Info:

Tonnage: 2.5
Volts 60 Hz 208/230-1.
Phase 1.
Refrigerant Type R-22.
Line Connection Suction ID (In) 3/4
Line Connection Discharge ID (In) 3/8
Base Mounting Centers (In) 7 1/2 x 7 1/2.
Application OEM A/C Equipments.
Includes Crankcase Heater.

Run Capacitor is 35 uf 370 volt.Most condensing unit capacitors are dual capacitors, meaning they operate thecompressor and the fan. To purchase the correct capacitor you will need toknow the uf rating on the fan.

Start Capacitor. 145-174 220Volt

To properly install a Compressor you need to have and use the proper equipment and use proper installation technique. If you are not familiar with these techniques or you do not have the proper equipment then you SHOULD have a qualified HVAC tech to install your new compressor. If the compressor is damaged due to improper installation procedures, the liability falls to the installer. All Sales are Final and there are no warranties!
